A.

Physical and Environmental Specification

007-4047-001
Appendix A

Technical Specifications

The SGI 1100 server is designed to be mounted in a standard 19-inch rack. For
instructions on mounting the SGI 1100 server in a 19-inch rack, see Chapter 2 in the SGI
1100 User's Guide.
Table A-1 shows the physical specifications for the SGI 1100 server system
Table A-1 SGI 1100 Server Physical Specification
Height
Width
Depth
Weight
Temperature
Humidity
Vibration:
Operating (unpacked)
Non-operating (packed)
1u (1.75 in., 4.45 cm)
19.0 in. (48.25 cm)
21.2 in. (53.85 cm)
24.2 lbs. (11 kg), maximum configuration
32 lbs (14.5 kg), with rack slides
+5 °C (41 °F) to +35 °C (+95 °F) (operating)
-10 °C (14 °F) to +60 °C (+149 °F) (non-operating)
20% - 80% RH, non-condensing
5 - 16.2 Hz: 0.38 mm (peak to peak)
16.2 - 250 Hz: 0.2 G
5 - 27.1 Hz: 0.60 G
27.1 - 50 Hz: 0.4 mm (peak to peak)
50 - 500 Hz: 2.0 G
115
