11: D-brick2
164
A key (Torx screwdriver), which locks or unlocks the disk drives, is provided with each
D-brick2. A red indicator is visible in the center rectangular aperture in the handle if the
anti-tamper lock is locked, and a black indicator is visible when the lock is unlocked (see
Figure 11-3).
Indicator
aperture
Locked
Figure 11-3 Anti-Tamper Locking on D-brick2 Disk Drive
Anti-tamper lock
Unlocked
007-4653-001
