Technical Specifications
007-4653-001
48VDC (Internal components) LED
12VDC (L1 controller) LED
Power switch
48V
12V
Power
connector
PWR
Figure 6-3 Rear Panel of X-brick
Table 6-1 lists the technical specifications of the X-brick.
Table 6-1 X-brick Technical Specifications
Characteristic Specification
Height 6.64 in. (168.65 mm)
Width 17.5 in. (444.5 mm)
Depth 27.74 in. (698.50 mm)
Weight 69 lb (31.29 kg)
Input power 48 VDC (~225 W)
Slot 1
Slot 2
Slot 3
Slot 4
XIO 11

Technical Specifications

XIO card slots
XIO 10
93
