Figure 5-4 shows the location of the rear-panel components of the PX-brick.
48VDC
12VDC
PCI-X slot LEDs
Figure 5-4
Rear Panel of PX-brick
One LED lights yellow,
the other lights green
XIO
Connectors
XIO 10
External Components
XIO 11
85
