Feature
4 single-link, digital video inputs (DVI)
1 single-link digital video output
1 analog video output
1 Swap Ready port
Genlock input and loopthrough ports
DB9 stereo port
007-4653-001
Table 12-3 describes the ports of the compositor.
Compositor Ports
Table 12-3
Table 12-4 lists the specifications of the compositor.
Table 12-4 Compositor Specifications
Characteristic
Height
Width
Depth
Weight
Acoustic noise
Cooling Requirements
Power Consumption
AC input to power supply
Inrush current
Notes
Up to 165-MHz pixel clock per input
Up to 165-MHz output
Up to 400-MHz pixel clock video output;
RGB; 2000 by 2000 resolution at 120 Hz
Controls the compositor update with the graphics pipe updates
Genlocks the compositor video output to an external source
Controls CrystalEyes style stereo glasses
Description
3.36 in. (85.34 mm)
17.5 in. (444.5 mm)
20.5 in. (520.7 mm)
25 lb (11.34 kg)
50 dBA approximate
256 Btu / hour
90 watts maximum
100-120/200-240 Vac at 50-60 Hz (autoranging)
5 A maximum
Compositor
181
