14: Maintenance and Upgrade Procedures
220
Note: The anti-tamper lock must be unlocked. If the drive module is locked, insert
the Torx screwdriver (included with the disk drive) into the socket in the lower part
of the handle trim. Then turn it 90 degrees counterclockwise until the indicator
window is black. See Figure 14-15.
Indicator
window
Figure 14-15 Unlocking Anti-Tamper Lock
2. Release the carrier handle by pressing the latch in the handle towards the right.
3. Gently withdraw the drive carrier module approximately 1 inch (25mm), and then
wait 30 seconds for the drive to spin down.
4. After 30 seconds, withdraw the module from the drive bay. Replace it immediately;
follow the instructions in "Installing TP900 Drive Carrier Module" on page 216.
Torx screwdriver
