4: Rack Information

SGI UV 2000 System Rack Technical Specifications

56
Table 4-1 lists the technical specifications of the SGI UV 2000 series tall rack.
Table 4-1
Tall Rack Technical Specifications
Characteristic
Height
Width
Depth
Single-rack shipping
weight (approximate)
Single-rack system weight
(approximate)
Voltage range
Nominal
Tolerance range
Frequency
Nominal
Tolerance range
Phase required
Power requirements (max) 34.57 kVA (33.88 kW) approximate
Hold time
Power cable
Specification
79.5 in. (201.9 cm)
31.3 in. (79.5 cm)
45.8 in. (116.3 cm)
2,381 lbs. (1,082 kg) air cooled
2,581 (1,173 kg) water assist cooling
2,300 lbs. (1,045 kg) air cooled
2,500 lbs (1,136 kg) water assist cooling
North America/International
200-240 VAC /230 VAC
180-264 VAC
North America/International
60 Hz /50 Hz
47-63 Hz
Single-phase or 3-phase
16 ms
8 ft. (2.4 m) pluggable cords
007-5832-002
