3: Cx-brick
PWR
XIO-2
62
The IP53 node boards have the following node address space identifier (NASID)
assignment (see Figure 3-5):
• IP53 node board 1 is NASID n
• IP53 node board 2 id NASID n+1
• IP53 node board 0 id NASID n+2
• IP53 node board 3 id NASID n+3
0
NASID n+1 XIO-1
D
NUMAlink 1 Port A NUMAlink 8
C
B
A
Figure 3-5 NASID Assignment
l
X X
I I
NASID n XIO-3
O O
1 3
D D
3
Port H NUMAlink 7 Port G
2
1
0
A A
NASID n+3 XIO-0 NASID n+2
D
NUMAlink 6
C
B
A
X
I
O
0
Port F
007-4653-001
