9: Power Components
Technical Specifications
152
Table 9-2 lists the specifications of the power bay.
Power Bay Technical Specifications
Table 9-2
Characteristic
Height
Width
Depth
Weight
(with five power supplies)
Input voltage
Output voltage
Table 9-3 lists the specifications of the distributed power supplies.
Table 9-3 Power Supply Technical Specifications
Characteristic Specification
Height 5 in. (127 mm)
Width 2.8 in. (71.12 mm)
Depth 13 in. (330.2 mm)
Weight 7.5 lb (3.40 kg)
Input voltage 220 VAC
Output voltage 12 VDC and 48 VDC
Specification
5.12 in. (130.04 mm)
17.5 in. (444.5 mm)
23.87 in. (606.3 mm)
64.5 lb (29.26 kg)
220 VAC
12 VDC and 48 VDC
007-4653-001
