14: Maintenance and Upgrade Procedures

Installing SCSI Disk Drive

!
212
Before you install a SCSI disk drive, you must power off the IX-brick according to the
instructions in "Powering Off Server" on page 24.
Caution: To protect the server from ESD damage, SGI recommends that you use a
grounding wrist strap while installing the disk drive.
To install a SCSI disk drive, see Figure 14-11 and follow these steps:
1. Remove the drive bay cover to access the two SCSI disk drive bays (see panel 1 in
Figure 14-11).
Note: If you are installing only one SCSI disk drive, install it in the rightmost bay.
2. Position the SCSI drive assembly so that it engages the bay guide rails, and then
gently push the drive into the bay. Do not use the locking handle to push the drive
into the bay.
3. Swing the locking handle towards the chassis until the locking handle engages the
latch.
4. Snap on the drive bay cover.
After you finish installing the SCSI disk drive, power on the IX-brick according to the
instructions in "Powering On Server" on page 8.
