13: InfiniteReality Graphics Components
Technical Specifications
198
Table 13-4 lists the technical specifications of the N-brick.
N-brick Specifications
Table 13-4
Characteristic Specification
Height 3.3 in. (83.82 mm)
Width 17.38 in. (441.45 mm)
Depth 27.5 in. (698.50 mm)
Weight 29 lb (13.15 kg)
Input power 48 VDC (~ 60 W)
Table 13-5 lists the specifications of the N-brick ports.
Table 13-5 N-brick Port Specifications
Port Quantity
XIO 8
L1 1
Peak Transfer Rate
800 MBytes in each direction
12 Mbits/s
007-4653-001
