3: Cx-brick
54
Table 3-1 lists some of the differences between the Cx-brick and the C- and R-bricks.
Brick Comparison Chart
Table 3-1
Characteristic Cx-brick
Processors 0 to 16
Processor boards 4 IP53 node boards
Memory 1 GB to 32 GB
DIMMs 8 per node board
NUMAlink ports 4 internal and 4 external
XIO ports 1 to 4 external (1 per IP53 node board)
The following sections provide more detail about the components that make up the
Cx-brick (see Figure 3-2):
• "IP53 Node Boards" on page 56
• "Router Board" on page 57
• "Power Entry Module" on page 57
Warning:
To prevent personal injury, or damage to your system, only trained SGI
system support engineers (SSEs) can service the internal components of the Cx-brick.
C-brick R-brick
2 or 4 N/A
2 PIMMs N/A
1 GB to 8 GB N/A
8 per brick N/A
1 external 8 external
1 0
