8: System Control

L1 Front Panel Display

108
The front panel display of the L1 controller contains the following items (see Figure 8-2):
2 x 12 character liquid crystal display (LCD). The display uniquely identifies the
brick, shows system status, warns of required service, and identifies a failed
component.
On/Off switch with LED (button with light-emitting diode [LED]). This button
enables you to manually power on and power off the brick. The LED illuminates
when the brick is powered on.
Service required LED. This LED illuminates orange to indicate that an item is not
functioning properly (for example, a fan is off), but the brick is still operating.
Failure LED. This LED illuminates red to indicate that a failure has occurred and the
brick is down.
Reset switch. This switch resets the Cx-brick internal processors and ASICs. This
reset will cause a memory loss.
Non-maskable interrupt (NMI) button switch. This switch resets the Cx-brick
internal processors and ASICs and writes the contents of the registers and memory
to a /var/adm/crash file.
Note: The reset and NMI switches are available on the Cx-brick only.
007-4653-001
