PWR
Technical Specifications
007-4653-001
VPro V12 boards
SLOT 1
SLOT 2
SLOT 3
SLOT 4
Rear View of V-brick
Figure 12-3
Table 12-2 lists the technical specifications of the V-brick.
V-brick Technical Specifications
Table 12-2
Characteristic Specification
Height 6.64 in. (168.65 mm)
Width 17.5 in. (444.5 mm)
Depth 27.74 in. (698.50 mm)
Weight 69 lb (31.29 kg)
Input power 48 VDC (~300 W)
L
Genlock Swap Ready
L
Genlock Swap Ready
XIO 11 XIO 10
V-brick
R
R
179
