1: Operation Procedures
32
7. After you have selected the destination of the bricks you want to power off, select
Power DOWN from the home window; the power down confirmation window,
shown in Figure 1-23, appears. This window indicates which bricks will receive the
Power DOWN command. In this example, the window indicates that all slots
(bricks) in all racks (r * s*) will be powered off. If you select OK, the power-off
operation is confirmed and the home window appears. Selecting Cancel stops the
power-off operation and the home window appears.
SGI L2 Controller, Firmware xx.xx.x
L2-001 S/N Lxxxxxxx [firestorm]
Power: ON
Press the "OK" button to issue the
"r * s * power down" command.
OK
Power Down Confirmation Window
Figure 1-23
Cancel
007-4653-001
