The home window, shown in Figure 1-6, displays the following items:
• Firmware (xx.xx.x) version of the L2 controller.
• Rack number (L2-001) of the L2 controller to which the L2 controller touch display is
connected.
• System serial number (Lxxxxxxx).
• Server name in parentheses (firestorm).
• Power status (Power: OFF) for the bricks designated in the destination (DEST:)
field. For this example, all slots in all racks (r * s *), which amounts to 57 bricks, are
powered off.
• Four command buttons (Power UP, Power DOWN, RESET, and NMI) that when
selected activate a confirmation window for the command. The command is sent to
the bricks that are listed in the DEST: field after you okay the command from the
confirmation window.
• DEST: button that enables you to select the bricks that will receive a command. In
addition, to the right of this button is an area that lists the current brick selection.
For this example, all slots in all racks (r * s *), which amounts to 57 bricks, are
selected to receive a command.
