F - 160 OPERATION AND
MAINTENANCE MANUAL
© November 1999 GBC Pro-Tech
Do not duplicate without written permission.
Plane4
Plane4
Plane4
GBC Pro - Tech
4151 Anderson Road
DeForest, WI 53532
Revision : B
Ph: ( 608 ) 246 - 8844
Fx: ( 608 ) 246 - 8645
Part number : 930 - 031
