9 – Displaying Host, HBA, HBA Port, Device, and LUN Information

Displaying Device Information

The identifying information displays:
❑
❑
❑
❑
❑
❑
The link status information displays:
❑
❑
3. You can do the following:
❑
❑
❑
9.4
Displaying Device Information
You can view the following information about a device (disk or tape):
General device information
■
LUN list
■
9-14
Hostname. The name or IP address of the host connected to the HBA
HBA Model. The QLA200/QLA2xxx HBA
Port. HBA port number
Node Name. World wide HBA node name
Port Name. World wide HBA port name
Port ID. Port ID of the HBA port
Port Name. For the HBA port, the world wide HBA port name displays. For
each device, the world wide device port name displays.
Diagnostic information. For the HBA port and each device, the number of
link failures, loss of sync failures, signal failures, and number of invalid CRCs
display.
Click Reset Current to initialize the link counter values to zero.
Click Refresh Current to view the link counter values from when you
initialized them by clicking Reset Current.
Click Refresh Total to view the link counter values from when the system
was last booted.
(see section 9.4.2)
(see section 9.4.1)
Q
FS0054603-00 C
