7 – Setting Up Connections
Viewing a Saved Host Configuration from a File (.qlc)
2. When successful, the host configuration successfully saved to file message
displays. The message includes the path and file name (in the format
hostname_date_number.qlc).
NOTE:
7.10.2

Viewing the Host Configuration from a File

Perform the following steps to view the saved virtual host configuration from a .qlc
file.
NOTE:
1. Do one of the following:
❑
❑
❑
2. The Open dialog box displays. Select a .qlc file from the local working directory.
Click Open.
7-46
Write down the path and file name of the host configuration file.
You cannot view a virtual host configuration for a host that is currently
connected.
From the Host menu, select Load from File.
Right-click in the HBA tree. From the pop-up menu, select Load from File.
Press CTRL+O.
Q
FS0054603-00 C
