7 – Setting Up Connections
Binding Target Devices Attached to the HBA Port Using the Fibre Channel Port
7.7
Binding Target Devices Attached to the HBA Port Using the Fibre
Channel Port Configuration Dialog Box
NOTE:
Target persistent binding is done by associating a target ID with the world wide node
name and world wide port name of the target (targets can also be bound by port ID;
contact your authorized maintenance provider for more information). Persistent
binding information for targets is saved to persistent storage:
Registry (Windows 2000/Windows Server 2003)
■
/etc/modules.conf and /etc/qla2x00.conf files (Red Hat/SuSE Linux)
■
/kernel/drv/qla2x00.conf (Solaris SPARC)
■
Bind target devices to the attached HBAs using the Fibre Channel Port
Configuration dialog box, as described in the following steps:
1. To access the Fibre Channel Port Configuration dialog box, do the following
from the SANsurfer FC HBA Manager main window:
a. In the HBA tree, select the host (or HBA, HBA port, device, or LUN connected
b. Do one of the following:
7-38
This feature is not supported in Novell NetWare.
■
You can also use the General Configuration Wizard (Target Persistent
■
Binding dialog box)

tabbed page

(see section 7.8)
information about deleting persistent configuration data,
to the host).
Click the Configure button on the toolbar.
❑
From the Host menu, click Configure.
❑
Right-click the host, HBA, HBA port, device, or LUN in the HBA tree. From
❑
the pop-up menu, select Configure.
Press CTRL+C.
❑
(see section 7.2) or the Target Persistent Binding
to bind devices attached to HBA ports. For
Q
see section 7.9.
FS0054603-00 C
