Installing the bezel assembly

To install the bezel assembly, complete the following steps.
1. Connect the control-panel cable to the control-panel connector on the system
2. Carefully slide the bezel assembly onto the blade server until it clicks into place.
3. Install the blade server cover (see "Installing the blade server cover" on page
4. Install the blade server into the BladeCenter unit (see "Installing the blade
148
BladeCenter JS21 Types 7988 and 8844: Problem Determination and Service Guide
Bezel-assembly
release
Control-panel
connector
Control-panel
cable
board.
146).
server in a BladeCenter unit" on page 144).
Bezel-assembly
release
Bezel
assembly
