SRN FFC
ssss-122 ssss
ssss-124 ssss
ssss-126 ssss
252B
ssss-128 252B
ssss
software
ssss-129 252B
ssss
software
ssss-130 ssss
ssss-132 ssss
ssss-134 252B
software
102
BladeCenter JS21 Types 7988 and 8844: Problem Determination and Service Guide
Description and action
A SCSI reservation conflict error.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
A SCSI check condition error occurred.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
A software error was caused by a hardware failure.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
The error log analysis indicates a hardware failure.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
Error log analysis indicates a SCSI bus problem.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
Error log analysis indicates a problem reported by the disk drive's self-monitoring
function.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
A disk drive hardware error occurred.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
The adapter failed to configure.
1. Check the BladeCenter management module event log. If an error was recorded
by the system or if a checkpoint code is displayed on the console, see "POST
checkpoint codes" on page 9.
2. Replace any parts reported by the diagnostic program.
3. Replace the system-board and chassis assembly.
