IBM BladeCenter JS21 Types 8844 Service Manual page 100

SRN Description
A03-13x I/O Expansion bus parity error.
A03-14x I/O Expansion bus time-out error.
A03-15x I/O Expansion bus connection failure.
A03-16x I/O Expansion unit not in an operating state.
A05-00x Error log analysis indicates an environmental
and power warning, but the failure could not
be isolated.
A05-01x Sensor indicates a fan has failed.
A05-02x System shutdown due to a fan failure.
A05-03x Sensor indicates a voltage outside normal
range.
84
BladeCenter JS21 Types 7988 and 8844: Problem Determination and Service Guide
FRU/action
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
1. Check the BladeCenter management module event
log; if an error was recorded by the system or if a
checkpoint code is displayed on the console, see
"POST checkpoint codes" on page 9.
2. If no entry is found, replace the system-board and
chassis assembly.
