7. Windrowers with self-aligning center-link: Release center-
link latch (A).
8. Disengage the safety props on both lift cylinders as follows:
a. Turn lever (A) away from the header to raise the safety
prop until the lever locks into the vertical position.
b. Repeat the previous step for the opposite cylinder.
NOTE:
If the safety prop will NOT disengage, raise the header to
release the prop.
9. Start the engine.
262175
ATTACHING HEADERS TO WINDROWER
190
Figure 5.206: Center-Link
A
Figure 5.207: Safety Prop Lever
A
