MacDon M150 Supplement Manual

Supplement to M150/M200 Operator's Manual. See manual for greater detail.
Break-In Period Services
HRS ITEM
0.25
Road or Drive Wheel Nuts
1 Field
A/C Belt Tension
Caster Wheel Nuts
Caster Wheel Anti-
5
Shimmy
Dampener Bolts
Walking Beam Bolts
Walking Beam Bolts
10
Drive Wheel Nuts
Neutral
Hose Clamps - Air
Intake, Radiator,
Heater, Hydraulic
Walking Beam Bolts
Caster Wheel Anti-
Shimmy
Dampener Bolts
50
Drive Wheel Nuts
Engine Gearbox Oil
Drive Wheel Oil
Hydraulic Oil filters
100 Main Gearbox Oil
150 Main Gearbox Oil
Lubricant Specifications
Lubricant Volume
Grease N/A
15.8 US
CAT
Qt (15L)
Engine
Oil
10.6 US
Cummins
Qt (10L)
17.2 US
Hydraulic Oil
Gal (66L)
Engine 2.2 US Qt
gearbox (2.1L)
Gear
Lube
Power 1.5 US
Wheels Qt (1.4L)
Form 169414
M150/M200 QUICK CARD
CHECK
Torque - 175-200 ft-lb (237-271 Nm)
Tension
Torque - 115-127 ft-lb (156-172 Nm)
Inboard Bolt Torque - 100 ft-lb (135 Nm)
Outboard Bolt Torque - 85 ft-lb (115 Nm)
Torque - 330 ft-lb (448 Nm)
Torque - 330 ft-lb (448 Nm)
Torque - 175-200 ft-lb (237-271 Nm)
Dealer Adjust if Required
Tighten
Torque - 330 ft-lb (448 Nm)
Inboard Bolt Torque - 100 ft-lb (135 Nm)
Outboard Bolt Torque - 85 ft-lb (115 Nm)
Torque - 175-200 ft-lb (237-271 Nm)
Repeat Checks Until Torque Stabilizes
Change
Change
Change
Check
Check
Specification Use
SAE Multi-
Purpose. High
Temp, Extreme
Pressure EP2.
As required.
Max 1%
molybdenum
disulphide.
Lithium base
SAE 15W40 for
API Class CH-4 Engine
& C1-4 Engine Crankcase
Oil
SAE 15W40 for
Engine
API Class SJ &
Crankcase
CH-4 Engine Oil
SAE 15W40 for
Windrower &
API Class SJ &
Header Drive
CH-4 Engine Oil
SAE 75W-90 API
Service Class
GL-5. E Synthetic
Power Wheels
Trans Lube
and Engine
SAE 75W-90 API Gearbox
Service Class
GL-5. E Synthetic
Trans Lube
1. Check Tire Inflation
2. Check Engine Oil and Engine Coolant Levels
10 Hrs or 3. Clean Radiator, Hyd Oil Cooler, Charge Air Cooler, A/C
Daily Condenser
4. Check Hydraulic Oil Level, Hoses and Lines for leaks.
5. Drain Fuel Filter Water Tap
1. Grease Caster Pivots and Spindle Bearings
2. Grease Walking Beam Center Pivot
50 Hrs 3. Grease Top Link Pivots
4. Clean Cab Fresh Air Intake Filter
5. Check Engine Gearbox/Drive Wheel Lube
1. Check Drive Wheel Lubricant Level
200 Hrs or
2. Grease Formed Caster Wheel Hub Bearings
Annually
3. Check Wheel Nut Torque
1. Change Engine Oil and Filter (or annually)
2. Change Fuel Filters
3. Change Engine Gearbox Lubricant
4. Change Hydraulic Oil Filters
500 Hrs
5. Check Engine Valve Tappet Clearance- M200
6. Change Engine Air Cleaner Filter Element- M200
7. Change Crankcase Breather- M200 ONLY
8. Check Safety Systems (or annually)
1. Change Engine Air Cleaner Filter Element- M150
1000 Hrs 2. Change Drive Wheel Lubricant
3. Check Engine Valve Tappet Clearance
1. Change Hydraulic Oil
2000 Hrs
2. Perform General Engine Inspection
3. Change Engine Coolant (M150 ONLY)
3000 Hrs 1. Change Engine Coolant (M200 ONLY)
1. Change Fuel Tank Vent Line Filter
2. Check Battery Fluid Level & Battery Charge
Annually
3. Check Anti-Freeze Concentration
4. Cycle A/C Blower Switch to circulate Refrigerant Oil
Fuel Volume
97G
Diesel No.2
(378L)
Diesel No.1 97G
& 2 mix (378L)
Fluid Volume
5.3 US G
Anti-freeze
(20L)
A/C 3.6lbs
Refrigerant (163kg)
Compressor 8.1fl.oz
Oil (240cc)
Rev. A
General Services
Fluid Specifications
Water &
Sulphur
Spec Sediment
(by wgt)
(by wgt)
ASTM As per As per
D-975 Spec
1%max
n/a .1% max
.5% rec.
Spec Description
ASTM Ethylene Glycol Or Propylene-
Glycol With SCA.
D-4985
R134A Refrigerant
SP-15 Compressor
1 of 4
Page
Lubricity
As Per
Spec Spec
460
HFRR
