Servicing the Disk Backplane (FRU)

The following section describes how to service the disk backplane. The disk backplane is
a field-replaceable unit (FRU). For more information about FRUs, see
Breakdown" on page 20
The disk backplane should be removed and replaced only by authorized Oracle
Caution -
Service personnel.
Ensure that all power is removed from the server before removing or installing the
Caution -
disk backplane. You must disconnect the power cables before performing this procedure.
These procedures require that you handle components that are sensitive to
Caution -
electrostatic discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow electrostatic discharge safety measures and antistatic practices. See
"Electrostatic Discharge Safety" on page
To remove and install the disk backplane, follow these procedures:
"Remove the Disk Backplane" on page 159
■
"Install the Disk Backplane" on page 164
■
Related Information
"Servicing Storage Drives (CRU)" on page 69
■
"Servicing SAS Cables (FRU)" on page 189
■
"Servicing NVMe Cables (FRU)" on page 195
■

Remove the Disk Backplane

Prepare the server for service.
1.
and "Field-Replaceable Units" on page
52.
"Illustrated Parts
22.
Servicing the Disk Backplane (FRU) 159
