Diagnostic Tool Documentation; Attaching Devices To The Server; Attach Devices To The Server - Oracle X8-2L Service Manual

Attaching Devices to the Server

Diagnostic Tool Documentation

The following table identifies where you can find more information about diagnostic tools.
Diagnostic Tool
Oracle ILOM
UEFI Diagnostics or HWdiag
System indicators and sensors
Oracle VTS
Attaching Devices to the Server
The following sections contain procedural information for attaching devices to the server so you
can access diagnostic tools when troubleshooting and servicing the server:
"Attach Devices to the Server" on page 40
■
"Back Panel Connector Locations" on page 41
■
"Configuring Serial Port Sharing" on page 42
■
"Server Operating System Names for the NVMe Storage Drives" on page 44
■
"Ethernet Device Naming" on page 45
■
"MAC Address Mapping to Ethernet Ports" on page 45
■
"Back Panel Pinhole Switches" on page 46
■

Attach Devices to the Server

This procedure explains how to connect devices to the server (remotely and locally), so that you
can interact with the service processor (SP) and the server console.
40 Oracle Server X8-2L Service Manual • January 2021
Documentation
Oracle Integrated Lights Out Manager
5.0 Documentation Library
Oracle x86 Servers Diagnostics and
Troubleshooting Guide for Servers With
Oracle ILOM 5.0.x
This document
Oracle VTS software and
documentation
Location
https://www.oracle.com/goto/
ilom/docs
https://www.oracle.com/goto/
x86admindiag/docs
"Troubleshooting Using the Server
Front and Back Panel Status
Indicators" on page 30
https://docs.oracle.com/cd/
E83848_01/
