1. Connect an Ethernet cable to the Gigabit Ethernet (NET) connector as needed for
OS support.
See "Back Panel Connector Locations" on page
2. To connect to the service processor's Oracle ILOM over the network, connect an
Ethernet cable to the Ethernet port labeled NET MGT.
See "Back Panel Connector Locations" on page
3. To access the Oracle ILOM command-line interface (CLI) locally, connect a serial
null modem cable to the RJ-45 serial port labeled SER MGT.
To access the system console, connect the RJ-45 cable to a terminal or terminal emulator, log on
to Oracle ILOM, and type
See "Back Panel Connector Locations" on page

Back Panel Connector Locations

The following illustration shows and describes the locations of the back panel connectors. Use
this information to set up the server, so that you can access diagnostic tools and manage the
server during service.
41.
41.
.
start /HOST/console
41.
Attach Devices to the Server
Troubleshooting and Diagnostics 41
