Plug each cable into its NVMe connector until you hear an audible click.
Use the following table to ensure proper NVMe cable connections.
Oracle PCIe NVMe
Slot Location and
Cable Part Number
3 (7345518)
4 (7345517)
8 (7345517)
9 (7345518)
4. Return the server to operation.
a. Install the fan tray.
See "Install the Fan Tray" on page
b. Install the fan modules.
See "Install a Fan Module" on page
Install the air baffle.
c.
See "Install the Air Baffle" on page
d. Install the server top cover.
See "Install the Server Top Cover" on page
e. Return the server to the normal rack position.
See "Return the Server to the Normal Rack Position" on page
Reconnect the power cords to the power supplies, and power on the server.
f.
HBA Connector Disk Backplane
Connector
1 D
2 E
3 F
1 A
2 B
3 C
1 A
2 B
3 C
1 D
2 E
3 F
90.
87.
115.
Physical Storage
Drive Slots
2
6
10
3
7
11
1
5
9
0
4
8
218.
220.
Servicing NVMe Cables (FRU)
Install NVMe Cables
