Return the Server to the Normal Rack Position

Caution -
carry the chassis and install it in the rack.
1. Lift the server from the antistatic mat, and reinstall the server into the rack.
Refer to
Guide
2. If the cable management arm (CMA) is not installed, that is, you removed it
because you removed the server completely out of the rack, install the CMA.
For installation instructions for the CMA, refer to
(Optional)" in Oracle Servers X8-2 and X8-2L Installation
3. If the cables are disconnected from the back of the server, that is, you
disconnected the cables because you removed the server completely out of the
rack, reconnect the cables.
For instructions to reconnect cables to the back of the server, see
■
"Reconnect Power and Data Cables" on page
To identify the location of cable connectors on the back of the server, refer
■
to
Related Information
"Remove the Server From the Rack" on page 64
■
"Reconnect Power and Data Cables" on page 222
■
Return the Server to the Normal Rack Position
If the server is in the extended maintenance position, use this procedure to return the server to
the normal rack position.
1. Push the server back into the rack, as described in the following steps.
Simultaneously pull and hold the two green release tabs (one on each side
a.
of the slide rails on the server) toward the front of the server while you push
the server into the rack.
As you push the server into the rack, verify that the cable management arm (CMA) retracts
without binding.
220 Oracle Server X8-2L Service Manual • January 2021
The server weighs approximately 64.0 pounds (29.03 kg). Two people are required to
"Installing the Server Into a Rack" in Oracle Servers X8-2 and X8-2L Installation
for the installation instructions specific to your rackmount kit.
"Back Panel Connector Locations" on page
"Install the Cable Management Arm
Guide.
222.
41.
