2. When the server successfully boots, the System OK LED remains lit. When the System OK
LED and the SP OK LED indicators remain lit, the server is in Main power mode.
The green System OK LED indicator and the green SP OK indicator remain lit (no
Note -
blinking) when the server is in a normal operating state.
Server System-Level Status Indicators
There are seven system-level status indicators (LEDs), some of which are located on both the
server front panel and the back panel. For the location of the status indicators, see
Back Panel Components" on page
Status Icon
Indicator Name
Locate Button/
LED
Fault-Service
Required
System OK
Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
16. The following table describes these indicators.
Color State and Meaning
White Indicates the location of the server.
■ OFF – Server is operating normally.
■ FAST BLINK (250 ms) – Use Oracle ILOM to activate this LED
indicator to enable you to locate a particular system quickly and
easily.
■ Pressing the Locate button toggles the LED indicator fast blink on or
off.
Amber Indicates the fault state of the server.
■ OFF – The server is operating normally.
■ STEADY ON – A fault is present on the server. This LED indicator
lights whenever a fault indicator lights for a replaceable component
on the server.
When this LED indicator is lit, a system console message might
Note -
appear that includes a recommended service action.
Green Indicates the operational state of the chassis.
■ OFF – AC power is not present or the Oracle ILOM boot is not
complete.
■ STANDBY BLINK (on for 100 ms, off for 2900 ms) – Standby
power is on, but the chassis power is off and the Oracle ILOM SP is
running.
■ SLOW BLINK (1000 ms) – Startup sequence was initiated on
the host. This pattern begins soon after you power on the server.
This status indicates either: power-on self-test (POST) code
checkpoint tests are running on the server host system, or the host
is transitioning from the powered-on state to the standby state on
shutdown.
■ STEADY ON – The server is powered on, and all host POST code
checkpoint tests are complete. The server is in one of the following
"Front and
Troubleshooting and Diagnostics 31
