BIOS Advanced Menu PCH SATA Configuration
Options
The following table describes the BIOS Advanced Menu PCH SATA configuration options.
Setup Options
SATA Controller
Configure SATA as
SATA test mode
SATA RSTe Boot Info
SATA Mode Options
SATA HDD Unlock
SATA LED Locate
Support Aggressive Link Power
Management
Alternate Device ID on RAID
Load EFI Driver for RAID
NVRAM CYCLE ROUTER 0
ENABLE
NVRAM CR0 PCIE Root Port
Number
NVRAM CYCLE ROUTER 1
ENABLE
Options
Disable/Enable
AHCI/RAID
Disable/Enable
Disable/Enable
Disable/Enable
Disable/Enable
Disable/Enable
Disable/Enable
Disable/Enable
Disable/Enable
PCI Express Root Port 1...20
None PCI Express Root Port
Disable/Enable
Defaults
Enable
AHCI
Disable
Enable
Enable
Enable
Enable
Disable
Disable
Disable
Disable
BIOS Setup Utility Menu Options
BIOS Advanced Menu Selections
Description
Enable or disable SATA
controller.
Configure SATA as AHCI or
RAID.
Enable or disable SATA test
mode.
Enable this setting to provide
full int13h support for SATA
controller attached devices.
Note - This option is available
only if Configure SATA as is
set to RAID.
Select SATA mode related
options.
Enable or disable SATA HDD
unlock.
Enable or disable SATA LED
locate.
Enable or disable aggressive link
power management.
Enable or disable an alternate
device ID on RAID devices.
Note - This option is available
only if Configure SATA as is
set to RAID.
Load EFI driver in RAID mode.
Note - This option is available
only if Configure SATA as is
set to RAID.
Enable or disable cycle router 0
for NVRAM Remapping engine.
Choose a RootPort that is
enabled for router cycle 0 for
NVRAM engine.
Enable or disable cycle router 1
for NVRAM Remapping engine.
