Remove the Motherboard Assembly
b. Extend the server into the maintenance position.
See
c. Attach an antistatic wrist strap to your wrist, and then to a metal area of the
chassis.
See
d. Remove the server top cover.
See
2. If present, remove the Oracle Storage 12 Gb SAS PCIe RAID HBA, Internal card
and its associated super capacitor.
See "Remove the Internal HBA Card and HBA Super Capacitor" on page
Note -
squeezing the plastic hinges together and lifting the tray from the chassis.
3. Remove the following reusable components:
Caution -
with the slot numbers from which they were removed (PS0, PS1). This is required because the
power supplies must be reinstalled into the slots from which they were removed; otherwise, the
server key identity properties (KIP) data might be lost. When a server requires service, the KIP
is used by Oracle to verify that the warranty on the server has not expired. For more information
on KIP, see
Fan modules
■
See
Fan tray
■
See
Air baffle
■
See
PCIe cards
■
See
SAS storage drive cables (if present)
■
See
NVMe cables (if present)
■
