DIMM Population Rules

You have purchased new DIMMs and you want to use them to upgrade the server's memory.
■
In this scenario, you should adhere to DIMM population rules and follow the recommended
DIMM population order for optimal system performance.
Related information
"DIMM Population Rules" on page 122
■
"Populating DIMMs for Optimal System Performance" on page 123
■
"Using the Server Fault Remind Button" on page 127
■
"Identify and Remove a DIMM" on page 128
■
"Install a DIMM" on page 130
■
DIMM Population Rules
The population rules for adding DIMMs to the server are as follows:
The server supports 64-GB quad-rank (QR) Load-Reduced DIMMs (LRDIMMs) and 32-
■
GB dual-rank (DR) and 16-GB DR Registered DIMMs (RDIMMs).
Do not mix DIMM types in the server. For example, do not mix 64-GB LRDIMMs and 16-
■
GB or 32-GB RDIMMs in the same server. If the server has 64-GB LRDIMMs installed,
you cannot install 16-GB or 32-GB RDIMMs and vice versa.
If you are installing a mix of RDIMM sizes (for example, 16-GB and 32-GB), install the
■
larger size RDIMMs first, then the smaller RDIMMs, until all of the RDIMMs are installed.
Each memory channel is composed of a black slot (channel slot 0) and a white slot (channel
■
slot 1). Populate the black slot first, and then populate the white slot.
Note -
furthest away from the processor.
The server supports either one DIMM per channel (1DPC) or two DIMMs per channel
■
(2DPC).
The server operates properly with a minimum of one DIMM installed per processor.
■
The server does not support lockstep memory mode, which is also known as double device
■
data correction, or Extended ECC.
Mixing of single-rank and dual-rank DIMMs in Oracle Server X8-2L is not supported.
■
122 Oracle Server X8-2L Service Manual • January 2021
The black slot for each channel must be populated first because it is considered
