Remove the Disk Backplane
a. Power off the server and disconnect the power cords from the power
supplies.
See
Extend the server into the maintenance position.
b.
See
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
c.
chassis.
See
d. Remove the server top cover.
See
e. Remove the air baffle.
See
f. Remove the fan modules from the server.
See
g. Remove the fan tray from the server.
See
Pull each storage drive out far enough to disengage it from the backplane.
2.
See "Remove a Storage Drive" on page
Note -
pull them out far enough to disengage them from the backplane. If you do remove the storage
drives from the server, make a note of their locations so that you can reinstall them in the same
locations.
3. Disconnect the cables from the disk backplane.
a. Disconnect the power cable from the disk backplane [1].
b. Depending on your storage drive configuration, do one of the following:
■
160 Oracle Server X8-2L Service Manual • January 2021
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
"Remove the Server Top Cover" on page
"Remove the Air Baffle" on page
"Remove a Fan Module" on page
"Remove the Fan Tray" on page
It is not necessary to completely remove the storage drives from the server; simply
Disconnect the three SAS cables from the disk backplane [1].
55.
65.
65.
113.
85.
89.
72.
62.
