Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
/SYS/MB/NET[0-x]
/SYS/MB/PCIE[1-x]
/SYS/MB/PCIE[1-x]/PRSNT
/SYS/MB/PCIE[1-x]/PCIESW
/SYS/MB/PCIE[1-x]/PCIESW/PRSNT
/SYS/MB/T_OUT_ZONE[0-2]
/SYS/MB/T_IN_ZONE[0-2]
/SYS/SP
/SYS/SP/OK
/SYS/SP/NET[0-1]
/SYS/MB/M2R[0-1]/
/SYS/MB/M2R[0-1]/SSD0
/SYS/MB/M2R[0-1]/PRSNT
/SYS/MB/M2R[0-1]/SSD0/PRSNT
/SYS/MB/M2R[0-1]/SSD0/STATE
/SYS/MB/M2R[0-1]/SSD0/NVME
/SYS/MB/M2R[0-1]/SSD0/NVME/
PRSNT
Related Information
"System Chassis Components" on page 291
■
"Cooling Unit Components" on page 293
■
"Disk Backplane Components" on page 294
■
298 Oracle Server X8-2L Service Manual • January 2021
IPMI Type Description
FRU Host Ethernet FRU
FRU PCIe slot
Discrete sensor PCIe slot is occupied.
FRU PCIe switch for NVMe support
Discrete sensor PCIe switch for NVMe support is
installed in this PCIe slot.
Threshold sensor Cooling zone output temperature
sensor
Threshold sensor Cooling zone input temperature
sensor
FRU Service processor FRU
Indicator SP OK LED
FRU SP Ethernet FRU
FRU M.2 SSD riser
FRU Internal M.2 SSD drives
Discrete sensor M.2 riser presence
Discrete sensor M.2 SSD drive presence
State sensor M.2 SSD drive state sensor
FRU Internal M.2 SSD is NVMe
Discrete sensor Indicates the M.2 SSD is PCIe
(NVMe).
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Degrees Celsius
Degrees Celsius
Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
04h-INSTALLED
20h-SLOT_POWER_OFF
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
