Oracle X8-2L Service Manual page 193

SAS cable assembly, part number 7117387 is required to connect the HBA card to the
Note -
disk backplane.
If your server is configured with Oracle Storage 12 Gb SAS PCIe HBA, Internal (non-
Note -
RAID) cards, reconnect the SAS cables to the Oracle Storage 12 Gb SAS PCIe HBA, Internal
cards located in PCIe slots 10 and 11.
3. Reconnect the SAS cables to the disk backplane [3].
Plug each cable into its SAS connector until you hear an audible click.
When attaching SAS cables, ensure that you match the numbers on the SAS cables with the
SAS connectors on the disk backplane and on the HBA card. Use the following table to ensure
proper SAS connections between the disk backplane and HBA cards.
HBA Card
Oracle Storage 12 Gb SAS
PCIe RAID HBA, Internal
Oracle Storage 12 Gb SAS
PCIe HBA, Internal
Oracle Storage 12 Gb SAS
PCIe HBA, Internal
Return the server to operation.
4.
a. Install the fan tray.
See "Install the Fan Tray" on page
Install the fan modules.
b.
See "Install a Fan Module" on page
c. Install the air baffle.
See "Install the Air Baffle" on page
d. Install the server top cover.
See "Install the Server Top Cover" on page
PCIe Slot HBA Connector
Location
11 1
2
3
11 1
2
10 3
90.
87.
115.
218.
Install SAS Storage Drive Cables
Disk Backplane Storage Drives
Connector
1 0, 1, 2, 3
2 4, 5, 6, 7
3 8, 9, 10, 11
1 0, 1, 2, 3
2 4, 5, 6, 7
3 8, 9, 10, 11
Servicing SAS Cables (FRU) 193
