Assign Serial Port Output Using the Oracle ILOM Web Interface
The Serial Port Settings page appears.
Note -
4.
In the Serial Port Settings page, select Host Server as the serial port owner.
5.
Click Save for the changes to take effect.
Connect a serial host to the server.
6.
Server Operating System Names for the NVMe
Storage Drives
If NVMe storage drives are installed in the server front panel, they are labeled NVMe0 through
NVMe11. The server operating systems assign these storage drives different names. For the
corresponding names assigned by the operating systems, see the following table. The drive
names provided in the table assume that:
Oracle PCIe NVMe switch cards are installed in PCIe slots 3, 4, 8, and 9
■
NVMe cabling between the Oracle PCIe NVMe switch cards and the disk backplane is
■
correct
Storage Drive Labels
NVMe0
NVMe1
NVMe2
NVMe3
NVMe4
NVMe5
NVMe6
NVMe7
NVMe8
NVMe9
NVMe10
NVMe11
44 Oracle Server X8-2L Service Manual • January 2021
The serial port sharing setting, by default, is Service Processor.
Names Assigned by the Server
Operating Systems
PCIe Slot 900
PCIe Slot 801
PCIe Slot 302
PCIe Slot 403
PCIe Slot 904
PCIe Slot 805
PCIe Slot 306
PCIe Slot 407
PCIe Slot 908
PCIe Slot 809
PCIe Slot 310
PCIe Slot 411
