Oracle X8-2L Service Manual page 278

BIOS Advanced Menu Selections
Setup Options
Connection Retry Count
Connection Establishing
Timeout
Configure ISID
Enable DHCP
Initiator IP Address
Initiator Subnet Mask
Gateway
Target Name
Target IP address
Target Port
Boot LUN
Authentication Type
CHAP Type
CHAP Name
278 Oracle Server X8-2L Service Manual • January 2021
Options
0 to 16
NA
Derived from the MAC address
Disabled/Enabled
NA
NA
NA
NA
0.0.0.0
CHAP/None
One Way/Mutual
NA
Defaults
0
1,000
The default value is derived
from the MAC address
Disabled
0.0.0.0
0.0.0.0
0.0.0.0
NA
None
3260
0
CHAP
One Way
None
Description
then the iSCSI driver attempt to
connect using the IPv6 stack.
The count range is 0 to 16. If set
to 0, there are no retries.
The timeout value in
milliseconds. The minimum
value is 100 milliseconds and
the maximum is 20 seconds.
The OUI-format ISID is 6 bytes.
The default value is derived
from the MAC address. Only the
last 3 bytes are configurable.
Example: Update
0ABBCCDDEEFF to
0ABBCCF07901 by inputting
F07901
Enable or disable DHCP.
Set initiator IP address in dotted-
decimal notation.
Set initiator subnet mask IP
address in dotted-decimal
notation.
Set initiator gateway IP address
in dotted-decimal notation.
The worldwide unique name of
the target. Only IQN format is
accepted.
Set target IP address in dotted-
decimal notation.
Change target port number.
Set the hexadecimal
representation of the boot logical
unit number (LUN).
Example: 4752-3A4F-6b7e-
2F99
Define the Challenge-
Handshake Authentication
Protocol (CHAP). Available
settings are CHAP, Kerberos,
and None.
Set CHAP type to either One
Way or Mutual.
Set CHAP name.
