Oracle X8-2L Service Manual page 215

Power supplies
■
See "Install a Power Supply" on page
PCIe cards
■
See "Install a PCIe Card" on page
NVMe cables (if present)
■
See "Install NVMe Cables" on page
SAS storage drive cables (if present)
■
See "Install SAS Storage Drive Cables" on page
Fan tray
■
See "Install the Fan Tray" on page
Fan modules
■
See "Install a Fan Module" on page
Air baffle
■
See "Install the Air Baffle" on page
If present, install the Oracle Storage 12 Gb SAS PCIe RAID HBA, Internal card
6.
and its associated super capacitor.
See "Install the Internal HBA Card and HBA Super Capacitor" on page
Before you install the HBA super capacitor, install the HBA super capacitor tray by
Note -
squeezing the plastic hinges together and inserting the tray into the chassis.
7. Return the server to operation.
Install the server top cover.
a.
See "Install the Server Top Cover" on page
b. Return the server to the normal rack position.
See "Return the Server to the Normal Rack Position" on page
c. Reconnect the power cords to the power supplies, and power on the server.
See "Reconnect Power and Data Cables" on page 222
Server" on page
Verify that the power supply AC OK LED is lit.
d.
96.
137.
198.
90.
87.
115.
222.
Install the Motherboard Assembly
192.
185.
218.
220.
and "Power On the
Servicing the Motherboard Assembly (FRU) 215
