Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Network Management Port Status Indicators
The server has one 10/100/1000BASE-T Ethernet management domain interface, labeled NET
MGT. There are two status indicators (LEDs) on this port. These indicators are visible from the
back of the server.
Status Indicator
Name
Activity
Link speed
Ethernet Port Status Indicators
The server has one 10/100/1000BASE-T Gigabit Ethernet port (NET 0). There are two status
indicators (LEDs) that are visible from the back of the server.
Status Indicator
Name
Activity
Link speed
Motherboard Status Indicators
The motherboard contains the following status indicators (LEDs).
Status Indicator
DIMM Fault Status
Indicators
34 Oracle Server X8-2L Service Manual • January 2021
Location Color State and Meaning
Top left Green ■ ON – Link up.
■ OFF – No link or down link.
■ BLINKING – Packet activity.
Top right Green ■ ON – 1000BASE-T link.
■ OFF – 10/100BASE-T link.
Location Color State and Meaning
Bottom left Green ■ ON – Link up.
■ OFF– No activity.
■ BLINKING – Packet activity.
Bottom Bi-colored: ■ OFF – 100BASE-T link (if link up).
right Amber/
■ Green ON – 1000BASE-T link.
Green
Description
■ Each of the 24 DIMM slots on the motherboard has an amber fault status indicator (LED)
associated with it.
■ If Oracle ILOM determines that a DIMM is faulty, pressing the Fault Remind button on
the motherboard I/O card signals the service processor to light the fault LED associated
with the failed DIMM.
