Disk Backplane Components

The following table lists the disk backplane (DBP) components.
Component Name (Oracle ILOM CLI Targets)
/SYS/DBP
/SYS/DBP/PRSNT
/SYS/DBP/HDD[0-x]
/SYS/DBP/HDD[0-x]/PRSNT
/SYS/DBP/HDD[0-x]/STATE
/SYS/DBP/HDD[0-x]/SERVICE
/SYS/DBP/HDD[0-x]/OK2RM
/SYS/DBP/HDD[0-x]/NVME
/SYS/DBP/HDD[0-x]/NVME/PRSNT
Related Information
"System Chassis Components" on page 291
■
"Cooling Unit Components" on page 293
■
"Memory Device Components" on page 295
■
"Power Unit Components" on page 295
■
294 Oracle Server X8-2L Service Manual • January 2021
IPMI Type Description
FRU Disk backplane FRU
Discrete sensor Disk backplane presence
Pseudo Hard disk drives (HDD)
Discrete sensor Hard disk drive presence
State sensor Hard disk drive state
Indicator Fault-Service Required
LED
Indicator Hard disk drive OK to
remove
FRU NVMe drive FRU
Discrete sensor NVMe device presence
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
01h-FAULT_STATUS
02h-IDENTITY
04h-INSTALLED
20h-SLOT_POWER_OFF
Color: Amber
Location: HDD
Off: Normal
On: HDD was diagnosed as failed
Color: Blue
Location: HDD
Off: Normal
On: HDD is OK to remove
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
