ST72361xx-Auto

Figure 76. Single master / multiple slave configuration

14.6

Low power modes

Table 56.
Mode
WAIT
HALT
Using the SPI to wake up the device from halt mode
In slave configuration, the SPI is able to wake up the device from HALT mode through a
SPIF interrupt. The data received is subsequently read from the SPIDR register when the
software is running (interrupt vector fetch). If multiple data transfers have been performed
before software clears the SPIF bit, then the OVR bit is set by hardware.
Note: When waking up from HALT mode, if the SPI remains in Slave mode, it is recommended to
perform an extra communications cycle to bring the SPI from HALT mode state to normal
state. If the SPI exits from Slave mode, it returns to normal state immediately.
Caution: The SPI can wake up the device from HALT mode only if the Slave Select signal (external
SS pin or the SSI bit in the SPICSR register) is low when the device enters HALT mode. So,
if Slave selection is configured as external (see
master drives a low level on the SS pin when the slave enters HALT mode.
SS
SCK
Slave
Device
MOSI MISO
MOSI MISO
SCK
Master
Device
5V SS
Effect of low power modes on SPI
No effect on SPI.
SPI interrupt events cause the device to exit from WAIT mode.
SPI registers are frozen.
In HALT mode, the SPI is inactive. SPI operation resumes when the device is
woken up by an interrupt with "exit from HALT mode" capability. The data
received is subsequently read from the SPIDR register when the software is
running (interrupt vector fetching). If several data are received before the wake-
up event, then an overrun error is generated. This error can be detected after
the fetch of the interrupt routine that woke up the Device.
SS
SCK
Slave
Device
MOSI MISO
Description
Slave select
Doc ID 12468 Rev 3
Serial peripheral interface (SPI)
SS
SCK SCK
Slave Slave
Device Device
MOSI MISO MOSI
management), make sure the
SS
MISO
151/279
