Pin Description; Figure 2. Lqfp 64-Pin Package Pinout - STMicroelectronics ST72361 Auto Series Manual

ST72361xx-Auto
1.1

Pin description

Figure 2. LQFP 64-pin package pinout
64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49
OSC1
1
OSC2
2
ARTIC1 / PA0
3
PWM0 / PA1
4
ei0
PWM1 / (HS) PA2 5
PWM2 / PA3
6
PWM3 / PA4
7
V
8
SS_3
V
9
DD_3
ARTCLK / (HS)PA5
10
ARTIC2 / (HS) PA6 ei0
11
T8_OCMP2 / PA7
12
T8_ICAP2 / PB0
13
T8_OCMP1 / PB1
14
ei1
T8_ICAP1 / PB2
15
ei1
MCO / PB3
16
17 18 19 20 21 22 23 24
Doc ID 12468 Rev 3
ei3
ei3
ei1
ei2
25 26 27 28 29 30 31 32
PD2 / LINSCI1_TDO
48
PD1 / LINSCI1_RDI
ei3 47
PF2 / AIN8
46
PF1 / AIN7
45
PF0
44
PE7
43
PD0 / SPI_SS / AIN6
ei3 42
V
41
DD_1
V
40
SS_1
PC7 / SPI_SCK
39
PC6 / SPI_MOSI
38
PC5 / SPI_MISO
37
PE6 / AIN5
36
PE5
35
PC4
34
PC3
33
(HS) 20mA high sink capability
eix associated external interrupt vector
(*) : by option bit:
T16_ICAP1 can be moved to PD4
T16_ICAP2 can be moved to PD1
T16_OCMP1 can be moved to PD3
T16_OCMP2 can be moved to PD5
Description
