Control Register 1 (SCICR1)

Read/ write
Reset value: x000 0000 (x0h)
7
R8
Bits 7:3 = Same function as in SCI mode, please refer to
description.
Bit 2 = PCE Parity control enable.
This bit is set and cleared by software. It selects the hardware parity control for LIN identifier
parity check.
0: parity control disabled
1: parity control enabled
When a parity error occurs, the PE bit in the SCISR register is set.
Bit 1 = reserved
Bit 0 = same function as in SCI mode, please refer to
description.
15.10.3

Control Register 2 (SCICR2)

Read/ write
Reset value: 0000 0000 (00h)
7
TIE
Bits 7:2 = same function as in SCI mode, please refer to
description.
Bit 1 = RWU Receiver wake-up.
This bit determines if the SCI is in mute mode or not. It is set and cleared by software and
can be cleared by hardware when a wake-up sequence is recognized.
0: receiver in active mode
1: receiver in mute mode
Note: Mute mode is recommended for detecting only the header and avoiding the reception of any
other characters. For more details please refer to
In LIN slave mode, when RDRF is set, the software can not set or clear the RWU bit.
Bit 0 = SBK Send break.
This bit set is used to send break characters. It is set and cleared by software.
0: no break character is transmitted
1: break characters are transmitted
Note: If the SBK bit is set to "1" and then to "0", the transmitter will send a BREAK word at the end
of the current word.
LINSCI serial communication interface (LIN master/slave)
T8 SCID
TCIE RIE
Doc ID 12468 Rev 3
M WAKE
Section 15.8: SCI mode register
Section 15.8: SCI mode register
ILIE TE
Section 15.8: SCI mode register
LIN reception.
PCE PS
RE RWU
0
PIE
0
SBK
