ST72361xx-Auto
Figure 4.
For external pin connection guidelines, refer to
LQFP 32-pin package pinout
OSC1
OSC2
PWM0 / PA1
PWM1 / (HS) PA2
ARTCLK / (HS) PA5
T8_OCMP1 / PB1
T8_ICAP1 / PB2
MCO / PB3
Doc ID 12468 Rev 3
32 31 30 29 28 27 26 25
PD2 / LINSCI1_TDO
1 24
ei3
23 PD1 / LINSCI1_RDI
2
ei3
3 22 PD0 / SPI_SS / AIN6
21 PC7 / SPI_SCK
4 ei0
5 20 PC6 / SPI_MOSI
19
6 PC5 / SPI_MISO
7 ei1 18 PC4
ei2
ei1
17
8 PC3
9 10 11 12 13 14 15 16
Chapter 20: Electrical
Description
(HS) 20mA high sink capability
eix associated external interrupt vector
(*) : by option bit:
T16_ICAP1 can be moved to PD4
T16_ICAP2 can be moved to PD1
T16_OCMP1 can be moved to PD3
T16_OCMP2 can be moved to PD5
characteristics.
23/279
