Electrical characteristics
depends on the number of supply pins in the device (3 parts*(n+1) supply pin). Two models
can be simulated: human body model and machine model. This test conforms to the
JESD22-A114A/A115A standard.
Static and dynamic latch-up
●
LU: three complementary static tests are required on 10 parts to assess the latch-up
performance. A supply overvoltage (applied to each power supply pin) and a current
injection (applied to each input, output and configurable I/O pin) are performed on each
sample. This test conforms to the EIA/JESD 78 IC latch-up standard. For more details,
refer to application note AN1181.
●
DLU: electrostatic discharges (one positive then one negative test) are applied to each
pin of three samples when the micro is running to assess the latch-up performance in
dynamic mode. Power supplies are set to the typical values, the oscillator is connected
as near as possible to the pins of the micro and the component is put in reset mode.
This test conforms to the IEC1000-4-2 and SAEJ1752/3 standards. For more details,
refer to application note AN1181.

Table 103. Absolute maximum ratings

Symbol
V
ESD(HBM)
V
ESD(MM)
V
ESD(CDM)
1. Data based on characterization results, not tested in production.

Table 104. Electrical sensitivities

Symbol
LU
DLU
1. Class description: A Class is an STMicroelectronics internal specification. All its limits are higher than the
JEDEC specifications, that means when a device belongs to Class A it exceeds the JEDEC standard. B
Class strictly covers all the JEDEC criteria (international standard).
240/279
Ratings
Electrostatic discharge voltage (human
body model)
Electrostatic discharge voltage (machine
model)
Electro-tatic discharge voltage (charge
device model)
Parameter
Static latch-up class
Dynamic latch-up class
Doc ID 12468 Rev 3
Conditions
 +25°C
T
A
Conditions
 +25°C
T
A
 +85°C
T
A
 +125°C
T
A
 5.5V, f  4 MHz, T
V
DD OSC
ST72361xx-Auto
(1)
Maximum value
2000
200
750 on corner pins,
500 on others
Class
A
 +25°C
A
Unit
V
(1)
