ST72361xx-Auto
20

Package characteristics

20.1

ECOPACK

In order to meet environmental requirements, ST offers these devices in different grades of
ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
ECOPACK
20.2

Package mechanical data

Figure 124. 32-pin low profile quad flat package (7x7)

D
D1
®
®
packages, depending on their level of environmental compliance. ECOPACK
®
is an ST trademark.
e
E1 E
b
L1
Doc ID 12468 Rev 3
Dim.
Min
A
A1 0.05
A
A2 1.35
A2
b 0.30
A1
C 0.09
D
D1
E
E1
e
c
q 0°
L
L 0.45
h
L1
N
1. Values in inches are converted from mm and rounded to
3 decimal digits.
Package characteristics
mm inches
Typ Max Min Typ
1.60
0.15 0.002
1.40 1.45 0.053 0.055
0.37 0.45 0.012 0.015
0.20 0.004
9.00 0.354
7.00 0.276
9.00 0.354
7.00 0.276
0.80 0.031
3.5° 7° 0° 3.5°
0.60 0.75 0.018 0.024
1.00 0.039
Number of Pins
32
®
(1)
Max
0.063
0.006
0.057
0.018
0.008
7°
0.030
257/279
