16-bit timer
12.7.13

Alternate counter low register (ACLR)

Read only
Reset value: 1111 1100 (FCh)
This is an 8-bit register that contains the low part of the counter value. A write to this register
resets the counter. An access to this register after an access to CSR register does not clear
the TOF bit in the CSR register.
7
MSB
12.7.14

Input capture 2 high register (IC2HR)

Read only
Reset value: Undefined
This is an 8-bit read only register that contains the high part of the counter value (transferred
by the Input Capture 2 event).
7
MSB
12.7.15

Input capture 2 low register (IC2LR)

Read only
Reset value: Undefined
This is an 8-bit read only register that contains the low part of the counter value (transferred
by the Input Capture 2 event).
7
MSB
Table 51.
Address
(Hex.)
51
52
53
122/279
16-bit timer register map
Register
7
name
CR2 OC1E OC2E
CR1 ICIE OCIE
CSR ICF1 OCF1
Doc ID 12468 Rev 3
6 5 4
OPM PWM
TOIE FOLV2
TOF ICF2
ST72361xx-Auto
3 2 1
CC1 CC0 IEDG2
FOLV1 OLVL2 IEDG1
OCF2 TIMD
0
LSB
0
LSB
0
LSB
0
EXEDG
OLVL1
