ST72361xx-Auto
12.7.9

Output compare 2 low register (OC2LR)

Read/ write
Reset value: 0000 0000 (00h)
This is an 8-bit register that contains the low part of the value to be compared to the CLR
register.
7
MSB
12.7.10

Counter high register (CHR)

Read only
Reset value: 1111 1111 (FFh)
This is an 8-bit register that contains the high part of the counter value.
7
MSB
12.7.11

Counter low register (CLR)

Read only
Reset value: 1111 1100 (FCh)
This is an 8-bit register that contains the low part of the counter value. A write to this register
resets the counter. An access to this register after accessing the CSR register clears the
TOF bit.
7
MSB
12.7.12

Alternate counter high register (ACHR)

Read Only
Reset value: 1111 1111 (FFh)
This is an 8-bit register that contains the high part of the counter value.
7
MSB
Doc ID 12468 Rev 3
16-bit timer
0
LSB
0
LSB
0
LSB
0
LSB
121/279
